YAMAHA VIXION

YAMAHA VIXION SPECIFICATION

Engine :

• Engine Type:
  • Vixion R: Liquid-Cooled, 4-Stroke, SOHC, 4-Valve, VVA
  • Vixion: Liquid-Cooled, 4-Stroke, SOHC
• Cylinder Configuration: Single Cylinder
• Displacement:
  • Vixion R: 155.1 cc
  • Vixion: 149.8 cc
• Bore × Stroke:
  • Vixion R: 58.0 mm × 58.7 mm
  • Vixion: 57.0 mm × 58.7 mm
• Compression Ratio:
  • Vixion R: 11.6 ± 0.4 : 1
  • Vixion: 10.4 : 1
• Maximum Power:
  • Vixion R: 14.2 kW @ 10,000 rpm
  • Vixion: 12.2 kW @ 8,500 rpm
• Maximum Torque:
  • Vixion R: 14.7 Nm @ 8,500 rpm
  • Vixion: 14.5 Nm @ 7,500 rpm
• Starting System: Electric Starter
• Lubrication System: Wet Sump
• Fuel System: Fuel Injection
• Clutch Type: Wet Multi-Plate Assist & Slipper Clutch
• Transmission Type: Manual

Chassis & Suspension :

• Frame Type: Deltabox
• Front Suspension: Telescopic Fork
• Rear Suspension: Swing Arm
• Tire Type: Tubeless
• Front Tire: 90/80-17M/C 46P
• Rear Tire:
  • Vixion R: 130/70-17M/C 62P
  • Vixion: 120/70-17M/C 58P
• Front Brake: Disc Brake
• Rear Brake: Disc Brake

Dimensions & Capacity :

Vixion R

• Overall Dimensions (L × W × H): 1,950 mm × 720 mm × 1,025 mm
• Wheelbase: 1,320 mm
• Ground Clearance: 165 mm
• Seat Height: 795 mm
• Curb Weight: 131 kg
• Fuel Tank Capacity: 11 Liters

Vixion

• Overall Dimensions (L × W × H): 1,955 mm × 720 mm × 1,025 mm
• Wheelbase: 1,295 mm
• Ground Clearance: 165 mm
• Seat Height: 795 mm
• Curb Weight: 132 kg
• Fuel Tank Capacity: 12 Liters

Electrical :

• Ignition System: TCI (Transistor Controlled Ignition)
• Battery: YTZ4V / GTZ4V
• Spark Plug Type:
  • Vixion R: NGK MR8E9
  • Vixion: NGK CR8E
