HONDA REVO X

HONDA REVO X SPECIFICATION

Engine :

• Engine Type: SOHC, 4-Stroke, Single Cylinder
• Engine Displacement: 109.17 cc
• Fuel System: Injection / PGM-FI (Programmed Fuel Injection)
• Bore x Stroke: 50 x 55.6 mm
• Transmission Type: 4-Speed
• Compression Ratio: 9.3:1
• Maximum Power: 6.56 kW (8.91 PS) @ 7,500 rpm
• Maximum Torque: 8.76 Nm (0.86 kgf·m) @ 6,000 rpm
• Starting System: Kick Starter & Electric Starter
• Clutch Type: Multiplate Wet Clutch with Diaphragm Spring
• Cooling System: Air-Cooled
• Gear Shift Pattern: N-1-2-3-4-N

Chassis & Suspension :

• Frame Type: Backbone (Tulang Punggung)
• Front Suspension Type: Telescopic Fork
• Rear Suspension Type: Swing Arm with Dual Shock Absorbers
• Front Tire Size: 70/90 – 17 M/C 38
• Rear Tire Size: 80/90 – 17 M/C 44P
• Front Brake: Hydraulic Disc Brake with Single Piston
• Rear Brake: Drum Brake

Dimensions & Weight :

• Length x Width x Height: 1,919 x 709 x 1,080 mm
• Wheelbase: 1,227 mm
• Minimum Ground Clearance: 135 mm
• Curb Weight: 97.5 kg

Fuel & Lubrication Capacity :

• Fuel Tank Capacity: 4 liters
• Engine Oil Capacity: 0.8 liters (periodic replacement)
