HONDA BEAT STREET

HONDA BEAT STREET SPECIFICATION

Engine :

• Engine Type: 4-Stroke, SOHC, eSP
• Bore x Stroke: 47.0 x 63.1 mm
• Displacement: 109.5 cc
• Compression Ratio: 10.0 : 1
• Maximum Power: 6.6 kW (9.0 PS) @ 7,500 rpm
• Maximum Torque: 9.2 Nm (0.94 kgf·m) @ 6,000 rpm
• Clutch Type: Automatic, Dry Centrifugal Clutch
• Starting System: Electric Starter
• Spark Plug Type: NGK MR9C-9N
• Fuel System: PGM-FI (Programmed Fuel Injection)
• Transmission Type: Automatic, V-Matic
• Ignition System: Full Transistorized Ignition System

Chassis & Suspension :

• Frame Type: Backbone Frame – eSAF (Enhanced Smart Architecture Frame)
• Front Suspension Type: Telescopic Fork
• Rear Suspension Type: Swing Arm with Single Shock Absorber
• Front Tire Size: 80/90 – 14 M/C 40P Tubeless
• Rear Tire Size: 90/90 – 14 M/C 46P Tubeless
• Front Brake: Hydraulic Disc Brake with Single Piston
• Rear Brake: Drum Brake
• Braking System: Combi Brake System (CBS)

Dimensions & Weight :

• Length × Width × Height: 1,876 × 669 × 1,080 mm
• Wheelbase: 1,255 mm
• Ground Clearance: 148 mm
• Seat Height: 742 mm
• Curb Weight: 89 kg

Capacity :

• Fuel Tank Capacity: 4.2 Liters
• Engine Oil Capacity: 0.65 Liters (Periodic Oil Change)

Electrical System :

• Battery: MF 12V–3Ah
