HONDA ADV 160

HONDA ADV 160 SPECIFICATION

Engine :

• Engine Type: 4-Stroke, 4-Valve, eSP+
• Cooling System: Liquid-Cooled
• Fuel Supply System: PGM-FI (Programmed Fuel Injection)
• Displacement: 156.9 cc
• Bore x Stroke: 60.0 x 55.5 mm
• Compression Ratio: 12.0 : 1
• Maximum Power: 11.8 kW (16 PS) @ 8,500 rpm
• Maximum Torque: 14.7 Nm (1.5 kgf·m) @ 6,500 rpm
• Transmission Type: Automatic, V-Matic
• Starting System: Electric Starter
• Clutch Type: Automatic, Dry Centrifugal Clutch
• Lubrication System: Wet Sump
• Engine Oil Capacity: 0.75 Liters (Periodic Oil Change)

Chassis, Suspension & Braking :

• Frame Type: Double Cradle
• Front Suspension: Telescopic Fork
• Rear Suspension: Twin Rear Shock Absorbers with Sub-Tank
• Front Tire: 110/80-14M/C Tubeless
• Rear Tire: 130/70-13M/C Tubeless
• Front Brake: Wavy Disc Brake
• Rear Brake: Wavy Disc Brake
• Braking System:
  • Triple-Pots Hydraulic Combined Brake System (CBS)
  • Anti-Lock Braking System (ABS) (ABS & Honda RoadSync Variant)

Dimensions & Capacity :

• Overall Dimensions (L × W × H): 1,950 mm × 763 mm × 1,196 mm
• Wheelbase: 1,324 mm
• Ground Clearance: 165 mm
• Seat Height: 780 mm
• Curb Weight:
  • 133 kg (CBS & ABS)
  • 134 kg (Honda RoadSync)
• Fuel Tank Capacity: 8.1 Liters

Electrical :

• Ignition System: Full Transistorized Ignition
• Battery Type: 12V – 5Ah Maintenance-Free (MF) Battery
• Spark Plug Type: NGK LMAR8L-9
• Power Charger: 5V / 3A
